Simplex Fiber Optic Pigtail, Multi-mode, 0.9mm
Please do not hesitate to contact us if you require any further information
Foreign Commercial Manager : +989125708854
0.9mm Fiber Optic Pigtail is used for telecom networks and also used for high speed metropolitan and access network.
Applications:
Telecommunication Networks
Local Area Network (LAN)
Connects Between fiber optic patch panel & network
Switch
- SC, LC, ST and FC connectors
- High return loss and low insertion loss
- High reliability and small bend radius
- Good exchangeability
- High tensile strength
- Available in low smoke zero halogen (LSZH) jacket
- Available in different fiber types and lengths
- Conforms to IEC, EIA-TIA performance requirements
- Lifetime Warranty
- Ceramic ferrules
- Guaranteed quality and performance
- 100% tested and recorded for insertion loss and return loss
- RoHS Compliant
- Semi tight buffered easy strip fiber
| Electrical and mechanical specification | |
| Data | Item |
| Optic Fiber Pigtail, Multi-mode, 0.9mm | Product name |
| SC/ST/FC/LC | Connector type |
| MM 0.9mm | Product type |
| According to request of customer | Length |
| PVC or LSZH or OFNR or OFNP(on request) | Cable jacket type |
| Simplex | Fiber Count |
| OM1, OM2, OM3, OM4 | Fiber type |
| <0.2dB | Insertion Loss |
| PC>45 dB , UPC>55 dB , APC>60 dB | Return loss |
| ≤0.2 dB 1000 times mating cycles | Repeatability |
| 0.9 mm | Cable Diameter |
| Orange, Aqua | Jacket Color |
| -40ºC to +85ºC | Operating Temperature |
| IEC 60784-1, IEC 61300, GR-326-CORE, GR-1435, ISO/IEC 11801, AS/NZS ISO/IEC 14763.3, IEC 61280-4-1, UL 94, ANSI/TIA-598C & RoHS | Standard |
| Item | Connector Type | Ferrule Type | Fiber Type | Cable Type | Jacket Material | Cable Color | Cable Diameter | Cable Length | |||||||
Fiber Optic Pigtail |
SC | UPC | G.652.D | Single Mode 9/125 | SX | Simplex | P | PVC | Y | Yellow | 9 | 0.9mm | 01 | 01 m | |
| G.657.A1 | Single Mode 9/125 | ||||||||||||||
| LC | G.657.A2 | Single Mode 9/125 | O | Orange | |||||||||||
| 02 | 02 m | ||||||||||||||
| G.655 | Single Mode 9/125 | 20 | 2.0mm | ||||||||||||
| W | Orange | ||||||||||||||
| ST | OM1 | Multi Mode 50/125 | |||||||||||||
| APC | OM2 | Multi Mode 50/125 | DX | Duplex | L | LSZH | A | Aqua | … | … | |||||
| FC | |||||||||||||||
| OM3 | Multi Mode 50/125 | B | Blue | 30 | 3.0mm | ||||||||||
| 99 | 99 m | ||||||||||||||
| MU | OM4 | Multi Mode 50/125 | G | Green | |||||||||||
