Optic Fiber Pigtail
Please do not hesitate to contact us if you require any further information
Foreign Commercial Manager : +989125708854
Optic Fiber Pigtail is used for telecom networks and also used for high speed metropolitan and
access network .
- SC, LC, ST and FC connectors
- Available in low smoke zero halogen (LSZH) jacket
- Conforms to IEC, EIA-TIA performance requirements
- Available in different fiber types and lengths
- Cable jacket color: Yellow
- RoHS, REACH and SVHC complian
Application
- CATV / VIDEO
- Passive Optical Network PON
- FTTX
- WDM, DWDM, ATM & SONET
- Data centers-support high speed multi-channel Video, data and voice services In metropolitan and access networks
| Electrical and mechanical specification | |
| Data | Item |
| Optic Fiber Pigtail | Product name |
| SC/ST/FC/LC/DIN | Connector type |
| SM/MM, 0.9mm/2.0mm/3.0mm | Product type |
| According to request of customer | Length |
| PVC or LSZH or OFNR or OFNP (on request) | Cable jacket type |
| Simplex | Fiber Count |
| SM or MM | Fiber type |
| <0.2dB | Insertion Loss |
| PC>45 dB , UPC>55 dB , APC>60 dB | Return loss |
| ≤0.2 dB 1000 times mating cycles | Repeatability |
| 0.9mm, 2 mm, 3mm | Cable Diameter |
| Yellow, Orange, Aqua | Jacket Color |
| -40ºC to +85ºC | Operating Temperature |
| IEC 60784-1, IEC 61300, GR-326-CORE, GR-1435, ISO/IEC 11801, AS/NZS ISO/IEC 14763.3, IEC 61280-4-1, UL 94, ANSI/TIA-598C & RoHS | Standard |
| Item | Connector Type | Ferrule Type | Fiber Type | Cable Type | Jacket Material | Cable Color | Cable Diameter | Cable Length | |||||||
Fiber Optic Pigtail |
SC | UPC | G.652.D | Single Mode 9/125 | SX | Simplex | P | PVC | Y | Yellow | 9 | 0.9mm | 01 | 01 m | |
| G.657.A1 | Single Mode 9/125 | ||||||||||||||
| LC | G.657.A2 | Single Mode 9/125 | O | Orange | |||||||||||
| 02 | 02 m | ||||||||||||||
| G.655 | Single Mode 9/125 | 20 | 2.0mm | ||||||||||||
| G | Green | ||||||||||||||
| ST | OM1 | Multi Mode 61.5/125 | |||||||||||||
| APC | OM2 | Multi Mode 50/125 | DX | Duplex | L | LSZH | A | Aqua | … | … | |||||
| FC | |||||||||||||||
| OM3 | Multi Mode 50/125 | V | Violet | 30 | 3.0mm | ||||||||||
| 99 | 99 m | ||||||||||||||
| MU | OM4 | Multi Mode 50/125 | |||||||||||||
