Wall-Mount Patch and Splice Panel

Please do not hesitate to contact us if you require any further information

Wall-Mount Patch and Splice Panel

Wall-Mount Patch and Splice Panel designed to support patching and splicing in one unit. The enclosure is suitable for indoor applications and to configure fiber to fiber or fiber to pigtail. It accommodates up to 72 connections and can use a wide range of connector types. Cabinets can be ganged together to accommodate capacities greater than 72 connections.
Quality of the product is tested according to IEC and ASTM Standards , as a result is reflected in their high quality and reliability.



  • The wall mounted box Protects from splicing & pigtail management in performance
  • Accommodates Up to 72 Fiber Ports
  • High resistance against water & dust (Compliant with IEC 60529)
  • Has wide area of communication that can be used for a variety of adaptors, FC, ST, SC, …
  • Available with Various Fiber Termination Connectors
  • Multiple Pigtail and Splice Tray Options Available
  • Has two cable outlets
  • Flexible design for fulfilling a range of demands
  • Easy installation & maintenance
  • High strength and durability
  • High Density
  • Double Door Entry with Lock
  • Available in RAL 7032 colors
  • Accessories are cable ties, glands, cassette cap, fiber splice protection sleeves, rawl bolts, nuts, hole filler caps, & Instructions
  • Easy operation, arrangement, splicing, slack storage and distribution
  • Used in telecom closets and remote distribution terminals
  • Compliant with RoHS

General Specifications
Capacity 48 adaptors, acc. to request of customer
Number of cassettes 4 to 6
Capacity of each cassette 12 Tray splices
Height 355 mm
Width 304 mm
Depth 84.6 mm
Accessories Cable ties, glands, cassette cap, fiber splice protection sleeves, rawl bolts, nuts, hole filler caps, & Instructions, acc.to picture
