Low Loss Antenna Cable
Please do not hesitate to contact us if you require any further information
Foreign Commercial Manager : +989125708854
Low loss antenna cable is a 1/2″ low loss physical foamed insulation coaxial cable and its impedance is 50 ohms. Low Loss coaxial cables are specifically designed to correspond to requirements of the mobile, cellular and broadcast networks. They deliver excellent performance for connections between the base station and antennas.
- Reliable
- Flexible
- Stable and Tough
- Excellent performance
- Low current loss
| Technical Specifications | ||||||
|---|---|---|---|---|---|---|
| Construction Specifications | ||||||
| Copper-clad aluminum wire | Inner conductor | |||||
| Physically foamed Polyethylene | Dielectric | |||||
| Ring Corrugated Copper | Outer Conductor | |||||
| PE or fire retardant PE | Jacket | |||||
| Physical Dimensions | ||||||
| 4.80±0.05 mm | Inner conductor diameter | |||||
| 12.20±0.30 mm | Dielectric diameter | |||||
| 13.80±0.20 mm | Outer Conductor diameter | |||||
| 15.80±0.20 mm | Jacket Diameter | |||||
| Electrical Specifications | ||||||
| 75.8 pF/m | Capacitance | |||||
| 50±1 ohms | Impedance | |||||
| 0.19 μH/m | Inductance | |||||
| ≤1.15 | VSWR | |||||
| 88 | Relative propagation velocity | |||||
| 8.8 GHz | Cut-off frequency | |||||
| 40 KW | Peak power | |||||
| 4.0 kV | DC breakdown voltage | |||||
| > 5000 MΩ/km | Insulation resistance | |||||
| >>120dB | Screening attenuation | |||||
| Mechanical & Environmental Specifications | ||||||
| 70 | Single | Bending radius, mm | ||||
| 125 | Repeated | |||||
| 350 | Moving | |||||
| 1130 | Pulling strength, N | |||||
| 2.0 | Crush resistance, kg/mm | |||||
| -70 C to +85 -40 C to +60 -55 C to +85 |
Store Installation Operation |
PE jacket | Recommended temperature | |||
| -30 C to +80 -25 C to +60 -30 C to +80 |
Store Installation Operation |
Fire retardant PE jacket | ||||
| Attenuation & Average Power | |||||
|---|---|---|---|---|---|
| Power rate @20C, kW | Nom.Attenuation@20C, dB/100m | Frequency MHz |
|||
| 11.3 | 0.67 | 10 | |||
| 3.49 | 2.17 | 100 | |||
| 1.59 | 4.75 | 450 | |||
| 1.338 | 5.97 | 690 | |||
| 1.17 | 6.46 | 800 | |||
| 1.1 | 6.85 | 900 | |||
| 1.04 | 7.28 | 1000 | |||
| 0.753 | 10.10 | 1800 | |||
| 0.71 | 10.70 | 2000 | |||
| 0.656 | 11.24 | 2200 | |||
| 0.620 | 11.78 | 2400 | |||
| 0.612 | 12.06 | 2500 | |||
| 0.604 | 12.34 | 2600 | |||
| 0.595 | 12.61 | 2700 | |||
| 0.565 | 13.40 | 3000 | |||
1/2″low loss physical foamed insulation coaxial cable , Hansen 1/2″ LCF Feeder , feeder cable 50 ohms, feeder 1/2 hansen 50ohms foam dielectric coaxial cable rf coaxial cable rf coaxil cable lcf12 transmission cable 50 ohms coaxial cable price and data sheet |
|||||
Maximum attenuation value shall be 105% of the nominal attenuation value
