SCF 7/8″ Feeder Cable
Please do not hesitate to contact us if you require any further information
Foreign Commercial Manager : +989125708854
SCF 7/8″ Feeder Cable is a super flexible coaxial cable and its impedance is 50 ohms and also its outer conductor and inner conductor made from Copper-tape longitudinal welded spiral corrugated. the antenna cable for fixed installation on board commercial ships without constant exposure to oil, grease and other lubricants.
- High quality
- Easy to use
- Stable and reliable
- Low attenuation
- Compatible with IEC 60332-3-24 (CAT C), IEC 60754-1 and -2
| Technical Specifications | |
|---|---|
| Product name | SCF 7/8″ Feeder Cable |
| Construction Specifications | |
| Copper-tape longitudinal welded spiral corrugated |
Inner conductor |
| Foam PE with skin | Dielectric |
| Copper-tape longitudinal welded spiral corrugated |
Outer Conductor |
| FRNC | Jacket |
| Physical Dimensions | |
| 9.3 mm | Inner conductor diameter |
| 21.6 mm | Dielectric diameter |
| 25.6 mm | Outer Conductor diameter |
| 27.7 mm | Outer Jacket diameter |
| Electrical Specifications | |
| 50±1 ohms | Impedance |
| Mechanical & Environmental Specifications | |
| 2.5 D | Bending radius, during operation |
| 3.75 D | Bending radius, during installation |
| -55 to+85 °C | Temperature range, during operation |
| -25 to+60 °C | Temperature range, during installation |
| Attenuation & Average Power | ||
|---|---|---|
| Typ.value at 40 °C kW |
Attenuation dB/100m |
Frequency MHz |
| 7.2 | 1.3 | 100 |
| 3.1 | 2.8 | 450 |
| 2.2 | 3.9 | 800 |
| 2.0 | 4.1 | 900 |
| 1.9 | 4.4 | 1000 |
| 1.35 | 6.2 | 1800 |
| 1.3 | 6.3 | 1900 |
| 1.17 | 6.9 | 2200 |
| 1.08 | 7.4 | 2500 |
| 1.02 | 7.7 | 2700 |
| 0.96 | 8.2 | 3000 |
